Gigabyte | PSU | GP-UD1000GM PG5 | W | 1000 W Padidinti

Power source Gigabyte GP-UD1000GM PG5 rev 2.0 1000W 80+

130,34 €

4719331553234

Galimas pasirinkimas

 pristatymas 5...7 d.d.


Fan diameter: 12 cm
Number of fans: 1 fan(s)
On/off switch: Yes
Product colour: Black
Fan location: Top
Power protection features: Over power, Short circuit, Over voltage, Under voltage, Over current
Efficiency: 90%
Total power: 1000 W
AC input frequency: 50 - 60 Hz
Input current: 15 - 6.5 A
AC input voltage: 100 - 240 V
Combined power (+5Vsb): 15 W
Max output current (+5V): 25 A
Hold time: 16 ms
Combined power (+12V): 999.6 W
Combined power (+5V): 125 W
Max output current (+3.3V): 25 A
Max output current (-12V): 0.3 A
Max output current (+12V): 83.3 A
Max output current (+5Vsb): 3 A
Combined power (+3.3V): 125 W
Power Factor Correction (PFC) type: Active
Combined power (-12V): 3.6 W
Depth: 150 mm
Height: 86 mm
Width: 140 mm
Purpose: PC
Mean time between failures (MTBF): 100000 h
80 PLUS certification: 80 PLUS Gold
Bearing technology: HDB
Package type: Box
Cables included: CPU, PCIe, Peripheral (Molex), SATA
Peripheral (Molex) power connectors (4-pin): 3
ATX power connector (20+4 pin): Yes
Cabling type: Fully-Modular
EPS power connector (4+4 pin): Yes
Floppy drive power connector: 1
CPU power connector (4+4 pin): Yes
Motherboard power connector: 20+4 pin ATX
PCI Express power connectors (6+2 pin): 6
Number of SATA power connectors: 8
CPU power cable length: 60 cm
Motherboard power cable length: 61 cm
Harmonized System (HS) code: 84733020
