Asus ROG STRIX B650E-F GAMING WIFI Processor family AMD Padidinti

ASUS ROG STRIX B650E-F GAMING WIFI AM5 DDR5 ATX MB

268,68 €

90MB1BQ0-M0EAY0

4711081944034

Galimas pasirinkimas

 3..5 d.d.


Processor socket: Socket AM5
Compatible processor series: AMD Ryzen™ 7
Processor manufacturer: AMD
Supported processor sockets: Socket AM5
Parallel processing technology support: Not supported
Motherboard form factor: ATX
Audio chip: Realtek ALC4080
Motherboard chipset family: AMD
Motherboard chipset: AMD B650
Audio output channels: 7.1 channels
Windows operating systems supported: Windows 11 x64
Supported memory clock speeds: 5800, 5400, 6000, 5600, 5000, 4800, 6400, 5200, 6200
Maximum internal memory: 128 GB
Unbuffered memory: Yes
Memory channels: Dual-channel
Memory slots type: DIMM
Supported memory types: DDR5-SDRAM
Number of memory slots: 4
Depth: 244 mm
Width: 305 mm
LAN controller: Intel I225-V
Bluetooth: Yes
Wi-Fi standards: 802.11g, Wi-Fi 5 (802.11ac), Wi-Fi 6E (802.11ax), 802.11b, Wi-Fi 4 (802.11n), 802.11a, Wi-Fi 6 (802.11ax)
Ethernet LAN: Yes
Wi-Fi: Yes
Ethernet interface type: 2.5 Gigabit Ethernet
Top Wi-Fi standard: Wi-Fi 6E (802.11ax)
Bluetooth version: 5.2
Number of SATA III connectors: 4
USB 2.0 connectors: 4
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 2
Number of chassis fan connectors: 4
Chassis intrusion connector: Yes
CPU fan connector: Yes
ATX Power connector (24-pin): Yes
S/PDIF out connector: Yes
Front panel audio connector: Yes
Thunderbolt headers: 1
EPS power connector (8-pin): Yes
USB 3.2 Gen 2 (3.1 Gen 2) connectors: 1
RGB LED pin header: Yes
Number of COM connectors: 1
Peripheral (Molex) power connectors (4-pin): 1
12V power connector: Yes
BIOS type: UEFI AMI
Clear CMOS button: Yes
Package weight: 9.22 kg
Package depth: 265 mm
Package width: 280 mm
Package height: 71 mm
Cables included: SATA
RAID support: Yes
Supported storage drive interfaces: M.2, SATA III
Supported storage drive types: HDD & SSD
RAID levels: 0, 1, 10
Ethernet LAN (RJ-45) ports: 1
DisplayPorts quantity: 1
USB 2.0 ports quantity: 4
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity: 1
HDMI ports quantity: 1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 4
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 2
Line-in: Yes
Microphone in: Yes
Headphone outputs: 3
Number of M.2 (M) slots: 3
PCI Express x16 (Gen 4.x) slots: 1
PCI Express x1 (Gen 4.x) slots: 2
PCI Express x16 (Gen 5.x) slots: 1
