Mainboard ASUS PRIME B660-PLUS D4 Padidinti

Mainboard ASUS PRIME B660-PLUS D4

139,24 €

4711081523017

Galimas pasirinkimas

 pristatymas 5...7 d.d.


Processor socket: LGA 1700
Supported processor sockets: LGA 1700
Processor manufacturer: Intel
Compatible processor series: Intel® Core™ i5, Intel® Celeron®, Intel® Core™ i7, Intel® Core™ i9, Intel® Pentium® Gold, Intel® Core™ i3
Motherboard chipset: Intel B660
Audio output channels: 7.1 channels
Motherboard chipset family: Intel
Power source type: ATX
Motherboard form factor: ATX
Windows operating systems supported: Windows 10 x64, Windows 11 x64
Unbuffered memory: Yes
Supported memory clock speeds: 2133, 4000, 4800, 2400, 2800, 3333, 3000, 3400, 3866, 2666, 4266, 3733, 4400, 5000, 4600, 3466, 5066, 2933, 3600
Supported memory types: DDR4-SDRAM
Maximum internal memory: 128 GB
Memory slots type: DIMM
Memory channels: Dual-channel
Number of memory slots: 4
Depth: 244 mm
Height: 53 mm
Width: 305 mm
Ethernet LAN: Yes
Ethernet interface type: 2.5 Gigabit Ethernet
Wi-Fi: No
S/PDIF out connector: Yes
Front panel audio connector: Yes
USB 2.0 connectors: 2
Number of COM connectors: 1
TPM connector: Yes
ATX Power connector (24-pin): Yes
Thunderbolt headers: 1
Number of SATA III connectors: 4
RGB LED pin header: Yes
Number of chassis fan connectors: 3
Chassis intrusion connector: Yes
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 2
Front panel connector: Yes
EPS power connector (8-pin): Yes
CPU fan connector: Yes
Clear CMOS jumper: Yes
BIOS type: UEFI AMI
Cables included: SATA
Supported storage drive interfaces: M.2, PCI Express 4.0, SATA III
RAID levels: 0, 1, 5, 10
RAID support: Yes
Number of HDDs supported: 4
Supported storage drive types: HDD & SSD
Number of storage drives supported: 7
Ethernet LAN (RJ-45) ports: 1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 1
HDMI version: 2.1
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity: 1
DisplayPorts quantity: 1
HDMI ports quantity: 1
Headphone outputs: 3
DisplayPort version: 1.4
USB connector type: USB Type-A, USB Type-C
USB 2.0 ports quantity: 2
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 2
VGA (D-Sub) ports quantity: 1
PCI Express x1 (Gen 3.x) slots: 2
PCI Express x16 (Gen 3.x) slots: 1
PCI Express x16 (Gen 4.x) slots: 1
Number of M.2 (M) slots: 3
Weight: 891 g
Harmonized System (HS) code: 84733020
