Asus TUF GAMING Z790-PLUS D4 Processor family Intel Padidinti

Asus | TUF GAMING Z790-PLUS D4 | Processor family Intel | Processor socket LGA1700 | DDR4 DIMM | Memory slots 4 | Supported har

233,41 €

90MB1CQ0-M0EAY0

4711081944973

Galimas pasirinkimas

 1..4 d.d.


Supported processor sockets: LGA 1700
Processor manufacturer: AMD
Compatible processor series: Intel® Core™ i7, Intel® Core™ i9, Intel® Pentium® Gold, Intel® Core™ i5, Intel® Celeron®, Intel® Core™ i3
Processor socket: LGA 1700
Parallel processing technology support: Not supported
Motherboard form factor: ATX
Motherboard chipset family: Intel
Audio chip: Realtek S1220A
Audio output channels: 7.1 channels
Windows operating systems supported: Windows 10 x64, Windows 11 x64
Motherboard chipset: Intel Z790
Power source type: ATX
Supported memory clock speed (max): 5333 MHz
Supported memory clock speeds: 3733, 4400 MHz, 5000, 4133, 4000, 4800, 2133, 3000, 5333 MHz, 3200, 2666, 4266, 4600, 2400, 2800, 4700, 5066, 3466, 4500, 3333, 3400, 3866, 2933, 3600, 5133
Supported memory types: DDR4-SDRAM
Memory slots type: DIMM
Memory channels: Dual-channel
Number of memory slots: 4
Maximum internal memory: 128 GB
Unbuffered memory: Yes
Depth: 244 mm
Height: 49 mm
Width: 305 mm
Ethernet LAN: Yes
Ethernet interface type: 2.5 Gigabit Ethernet
Wi-Fi: No
Number of SATA III connectors: 4
Number of COM connectors: 1
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 1
ATX Power connector (24-pin): Yes
Front panel audio connector: Yes
EPS power connector (8-pin): Yes
USB 3.2 Gen 2 (3.1 Gen 2) connectors: 1
12V power connector: Yes
Thunderbolt headers: 1
Number of chassis fan connectors: 4
CPU fan connector: Yes
RGB LED pin header: Yes
USB 2.0 connectors: 2
BIOS type: UEFI AMI
Package width: 340 mm
Package weight: 2.14 kg
Package height: 275 mm
Package depth: 70 mm
Cables included: SATA
User guide: Yes
Drivers included: Yes
Supported storage drive types: HDD & SSD
RAID support: Yes
Supported storage drive interfaces: M.2, SATA III
RAID levels: 1, 0, 5, 10
Number of storage drives supported: 8
Ethernet LAN (RJ-45) ports: 1
USB 3.2 Gen 2x2 Type-C ports quantity: 1
Line-in: Yes
HDMI version: 2.1
DisplayPort version: 1.4
DisplayPorts quantity: 1
Microphone in: Yes
S/PDIF out port: Yes
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 2
Headphone outputs: 1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 4
HDMI ports quantity: 1
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity: 1
Number of M.2 (M) slots: 4
PCI Express x1 (Gen 3.x) slots: 2
PCI Express x4 (Gen 4.x) slots: 1
PCI Express x16 (Gen 5.x) slots: 1
PCI Express x16 (Gen 4.x) slots: 1
Weight: 1.33 kg
