Gigabyte B760M DS3H DDR4 1.0 M/B Processor family Intel Padidinti

Gigabyte B760M DS3H DDR4 motherboard LGA 1700 micro ATX

104,33 €

B760M DS3H DDR4

4719331850876

Galimas pasirinkimas

 pristatymas 5...7 d.d.


Supported processor sockets: LGA 1700
Processor manufacturer: Intel
Compatible processor series: Intel® Core™ i7, Intel® Core™ i9, Intel® Pentium® Gold, Intel® Core™ i5, Intel® Celeron®, Intel® Core™ i3
Processor socket: LGA 1700
HDCP: Yes
Maximum resolution: 4096 x 2304 pixels
Parallel processing technology support: Not supported
Number of displays supported: 4
PC health monitoring: Fan, Voltage, Water cooling, Temperature
Motherboard chipset: Intel B760
Audio output channels: 7.1 channels
Motherboard form factor: micro ATX
Power source type: ATX
Windows operating systems supported: Windows 11, Windows 10
Motherboard chipset family: Intel
Supported memory clock speeds: 2400, 4700, 2933, 3600, 3300, 3000, 3733, 4300, 4400, 4500, 3400, 3866, 4133, 4000, 3666, 4800, 4933, 3200 MHz, 2666, 4266, 4600, 3800, 3333, 3466, 2133
Maximum internal memory: 128 GB
Unbuffered memory: Yes
Number of memory slots: 4
Memory channels: Dual-channel
Memory types supported by processor: DDR4-SDRAM
Supported memory types: DDR4-SDRAM
Memory slots type: DIMM
Supported memory clock speed (max): 4933 MHz
Width: 244 mm
Depth: 244 mm
Ethernet interface type: 2.5 Gigabit Ethernet
Ethernet LAN: Yes
S/PDIF out connector: Yes
USB 2.0 connectors: 2
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 1
Number of chassis fan connectors: 3
EPS power connector (8-pin): Yes
Parallel connector: Yes
Serial port headers: 1
Number of M.2 (M) slots: 2
Number of SATA III connectors: 4
Front panel audio connector: Yes
Front panel connector: Yes
CPU fan connector: Yes
TPM connector: Yes
ATX Power connector (24-pin): Yes
RGB LED pin header: Yes
Desktop Management Interface (DMI) version: 2.7
Clear CMOS jumper: Yes
BIOS type: UEFI AMI
Supported storage drive interfaces: M.2, SATA III
Supported storage drive types: HDD & SSD
RAID levels: 0, 1, 10, 5
RAID support: Yes
Number of storage drives supported: 6
DisplayPorts quantity: 2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 3
Headphone outputs: 1
Ethernet LAN (RJ-45) ports: 1
USB 2.0 ports quantity: 2
VGA (D-Sub) ports quantity: 1
HDMI ports quantity: 1
PS/2 ports quantity: 1
Line-in: Yes
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity: 1
PCI Express x16 (Gen 4.x) slots: 1
PCI Express x16 (Gen 3.x) slots: 1
Number of M.2 (M) slots: 1
