PROART B760-CREATOR WIFI | Processor family Intel | Processor socket LGA1700 | DDR5 DIMM | Supported hard disk drive interfaces Padidinti

ASUS 90MB1FY0-M0EAY0 motherboard Intel B760 LGA 1700 ATX

251,76 €

90MB1FY0-M0EAY0

4711387275962

Galimas pasirinkimas

 pristatymas 5...7 d.d.


Compatible processor series: Intel® Core™ i7, Intel® Core™ i9, Intel® Core™ i5, Intel® Core™ i3
Maximum number of SMP processors: 1
Processor manufacturer: Intel
Supported processor sockets: LGA 1700
Processor socket: LGA 1700
Audio output channels: 7.1 channels
Motherboard form factor: ATX
Cooling type: liquid
Motherboard chipset: Intel B760
Motherboard chipset family: Intel
Supported memory types: DDR5-SDRAM
Memory channels: Dual-channel
Memory slots type: DIMM
Number of memory slots: 4
Maximum internal memory: 192 GB
Wi-Fi standards: 802.11a, Wi-Fi 6 (802.11ax), Wi-Fi 4 (802.11n), 802.11g, 802.11b, Wi-Fi 5 (802.11ac)
WLAN controller model: Intel Wi-Fi 6 AX201
Top Wi-Fi standard: Wi-Fi 6 (802.11ax)
Ethernet LAN: Yes
Ethernet interface type: 2.5 Gigabit Ethernet, Gigabit Ethernet
Wi-Fi: Yes
USB 3.2 Gen 2 (3.1 Gen 2) connectors: 1
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 4
Power fan connector: Yes
ATX Power connector (24-pin): Yes
Audio connector: Yes
USB 2.0 connectors: 2
Supported storage drive interfaces: M.2, PCI Express 3.0, PCI Express 4.0
Supported storage drive types: SSD
USB 3.2 Gen 2x2 Type-C ports quantity: 1
DisplayPorts quantity: 1
USB connector type: USB Type-A, USB Type-C
Ethernet LAN (RJ-45) ports: 2
Headphone outputs: 5
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 4
USB 2.0 ports quantity: 6
HDMI ports quantity: 1
S/PDIF out port: Yes
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity: 1
PCI Express x16 (Gen 3.x) slots: 1
PCI Express x16 (Gen 4.x) slots: 1
Number of M.2 (M) slots: 3
PCI Express x16 (Gen 5.x) slots: 1
