Gigabyte B550I AORUS PRO AX 1.0 Processor family AMD Padidinti

Płyta główna Gigabyte B550I AORUS PRO AX

168,85 €

B550I AORUS PRO AX

4719331809508

Galimas pasirinkimas

 pristatymas 5...7 d.d.


Processor socket: Socket AM4
Compatible processor series: AMD Ryzen™ 3000 Series, AMD Ryzen™ 5000 Series, AMD Ryzen™ 5000 G-Series, AMD Ryzen™ 4000 G-Series
Processor manufacturer: AMD
Maximum resolution: 5120 x 2880 pixels
Graphics card family: AMD
HDCP: Yes
High Dynamic Range (HDR) supported: Yes
Motherboard chipset family: AMD
Cooling type: Active
PC health monitoring: Fan, Temperature, Water cooling, Voltage
Windows operating systems supported: Windows 11 x64, Windows 10 x64
Audio output channels: 7.1 channels
Motherboard chipset: AMD B550
Motherboard form factor: Mini-ITX
Power source type: ATX
Supported memory clock speeds: 4133, 4000, 4800, 2133, 2400, 5200, 3400, 3866, 3200, 4266, 2667, 3733, 4400, 4600, 5100 MHz, 5300, 2933, 3600, 3466
Supported memory module capacities: 32GB
Unbuffered memory: Yes
Maximum internal memory: 64 GB
Memory slots type: DIMM
Supported memory types: DDR4 SO-DIMM
Memory channels: Dual-channel
Number of memory slots: 2
Supported memory clock speed (max): 5300 MHz
Depth: 170 mm
Width: 170 mm
Wi-Fi: Yes
Ethernet interface type: Gigabit Ethernet
Bluetooth: Yes
Ethernet LAN: Yes
Bluetooth version: 5
Audio connector: Yes
USB 2.0 connectors: 1
Number of M.2 (M) slots: 2
TPM connector: Yes
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 1
Front panel audio connector: Yes
Front panel connector: Yes
EPS power connector (8-pin): Yes
Number of SATA connectors: 4
12V power connector: Yes
Number of chassis fan connectors: 2
Power fan connector: Yes
CPU fan connector: Yes
ATX Power connector (24-pin): Yes
Number of LED strips supported: 2
Desktop Management Interface (DMI) version: 2.7
Clear CMOS jumper: Yes
BIOS type: UEFI AMI
Supported storage drive types: SSD
RAID support: Yes
RAID levels: 10, 1, 0
Supported storage drive interfaces: M.2, PCI Express 3.0, PCI Express 4.0, SATA
DisplayPorts quantity: 1
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity: 1
HDMI ports quantity: 2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 4
Headphone outputs: 3
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 1
Ethernet LAN (RJ-45) ports: 1
PCI Express x16 slots: 1
PCI Express x1 slots: 1
