Mainboard Gigabyte B760M GAMING X AX Padidinti

Mainboard Gigabyte B760M GAMING X AX

147,31 €

B760M GAMING X AX

4719331853228

Galimas pasirinkimas

 pristatymas 5...7 d.d.


Supported processor sockets: LGA 1700
Processor socket: LGA 1700
Processor manufacturer: Intel
Compatible processor series: Intel® Core™ i7, Intel® Core™ i9, Intel® Pentium® Gold, Intel® Core™ i3, Intel® Core™ i5, Intel® Celeron®
Parallel processing technology support: Not supported
Maximum resolution: 4096 x 2304 pixels
HDCP: Yes
Windows operating systems supported: Windows 11, Windows 10
PC health monitoring: Fan, Voltage, Temperature, Water cooling
Audio output channels: 7.1 channels
Motherboard chipset family: Intel
Power source type: ATX
Motherboard form factor: micro ATX
Number of memory slots: 4
Memory channels: Dual-channel
Supported memory types: DDR5-SDRAM
Memory slots type: DIMM
Supported memory clock speeds: 7000, 6800, 7600, 6600, 5800, 5400, 5200, 6200, 6000, 4000, 4800 MHz, 7400, 6400, 5600, 7200
Maximum internal memory: 256 GB
Unbuffered memory: Yes
Supported memory clock speed (max): 7600 MHz
Width: 244 mm
Depth: 244 mm
Wi-Fi: Yes
Bluetooth version: 5.2
Ethernet interface type: 2.5 Gigabit Ethernet
Wi-Fi standards: Wi-Fi 5 (802.11ac), 802.11g, Wi-Fi 4 (802.11n), 802.11b, Wi-Fi 6E (802.11ax), 802.11a, Wi-Fi 6 (802.11ax)
Ethernet LAN: Yes
Top Wi-Fi standard: Wi-Fi 6E (802.11ax)
Bluetooth: Yes
RGB LED pin header: Yes
EPS power connector (8-pin): Yes
USB 3.2 Gen 2 (3.1 Gen 2) connectors: 1
Front panel connector: Yes
TPM connector: Yes
Front panel audio connector: Yes
S/PDIF out connector: Yes
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 1
Thunderbolt headers: 2
Serial port headers: 1
USB 2.0 connectors: 2
Number of chassis fan connectors: 3
ATX Power connector (24-pin): Yes
Number of SATA III connectors: 4
CPU fan connector: Yes
Desktop Management Interface (DMI) version: 2.7
Clear CMOS jumper: Yes
BIOS type: UEFI AMI
Number of storage drives supported: 6
RAID levels: 0, 10, 5, 1
Supported storage drive types: HDD & SSD
RAID support: Yes
Supported storage drive interfaces: M.2, SATA III
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 3
HDMI ports quantity: 1
Line-in: Yes
HDMI version: 2.0
Microphone in: Yes
WiFi-AP antenna jack: 2
USB 2.0 ports quantity: 5
Ethernet LAN (RJ-45) ports: 1
DisplayPorts quantity: 1
PCI Express x16 (Gen 4.x) slots: 1
Number of M.2 (M) slots: 1
PCI Express x16 (Gen 3.x) slots: 1
